easyMap Tools


easyMap works with Anritsu handheld spectrum analyzers and interference analyzers. It is focused on supporting option 25, Interference Analysis, and option 431, coverage mapping.

easyMap sources map data from either Google Maps or MapQuest. Maps sourced from Google can be displayed as Terrain Maps, Road Maps, Hybrid Maps (A combination of terrain and road maps) and as Satellite view maps. These maps are quite useful when used in interference hunting or coverage mapping. However, Google Maps is not available in every country, due to country specific restrictions. MapQuest sourced maps are available as road maps, and come from the OpenStreetMaps movement. At this time, they are freely downloadable wherever internet access is available.

easyMap translates the map source into a format readable by Anritsu handheld spectrum analyzers. This translation allows up to seven zoom levels on the instrument and allows panning and zooming on the instrument. The result is the ability to have the coverage you need to hunt interference or map coverage and at the same time, have the detail needed to locate what you find, even over a large geographic area.

easyMap enables accurate coverage mapping and interference hunting using an Anritsu handheld spectrum analyzer and the MA2700A interference hunter handle with a GPS, Compass, and Preamp. No more fussing with maps and compass, no more worrying about magnetic deviation or the effect of your truck motor on the compass heading. easyMap enables accurate signal measurement and location in the field.

easyMap Tools™ provides maps in formats that Anritsu's handheld spectrum analyzers can use for either coverage mapping or interference hunting. It helps users find and prepare geo-referenced maps and building floor plans for use by Anritsu handheld Spectrum Analyzers.

easyMap allows users to quickly:

  • Create geo-referenced maps with pan and zoom capability
  • Use either Google Maps or MapQuest (an Open Source map provider) to source maps
  • Create legacy mode geo-referenced maps
  • Convert maps and floor plans to a form suitable for use on Anritsu handheld spectrum analyzers
  • Insert GPS information into previously non-geo-referenced maps

These capabilities make it possible to find and prepare maps and floor plans for use on Anritsu handheld spectrum analyzers.

        easyMap coverage

Instruments Supported

Product Family


Interference Mapping
(Requires option 25,
Interference Analyzer)
Interference Mapping with pan
and zoom mode (AZM maps)
(Requires option 25,
Interference Analyzer)

Coverage Mapping
(Requires Option 431,
Coverage Mapping)

Site Master S332E X   X
S362E X   X
LMR Master S412E X   X
Cell Master MT8212E X   X
MT8213E X   X
BTS Master MT8221B   X X
MT8222B   X X
MT8220T   X X
Spectrum Master MS2712E X   X
MS2713E X   X
MS2722C X   X
MS2723C X   X
MS2724C X   X
MS2725C X   X
MS2726C X   X
MS2720T X   X
VNA Master MS2034B X   X
MS2035B X   X
PC Requirements

PC Requirements

Anritsu's software tools runs on computers using Windows
operating systems, specifically:

  • Windows XP, Service Pack 2 or higher
  • Windows Vista (32 bit or 64 bit)
  • Windows 7 (32 bit or 64 bit)
  • Windows 8 (32 bit or 64 bit)
  • Windows 10 (32 bit or 64 bit)

In addition, the PC must have at least:

  • 1 GB of RAM
  • 1 GB of available hard disk space
