The ShockLine™ MS46524B series are 4-port performance vector network analyzers (VNAs). Delivering an unprecedented level of value and performance in a multiport VNA, this series lowers the cost-of-test and speeds time-to-market in numerous test applications up to 43.5 GHz. These include: characterizing and manufacturing multiport mobile network devices and equipment for 28 GHz and 39 GHz 5G applications; differential cables; high-speed data interconnects; and system integration components.

The ShockLine MS46524B series, configured with Options 10, 20, or 43, brings RF to microwave frequency capabilities to this family. These frequency options, combined with powerful shockline software, provide a cost-effective solution for the most challenging, passive device testing.

For applications requiring time domain analysis, Options 2 and 22 are available. Option 2 enables the ShockLine MS46524B to provide differential and mixed-mode real-time bandpass and lowpass time domain functionality. Lowpass time domain enables a TDR-like display with capability of showing real impedance over distance or time. Option 22 equips the ShockLine MS46524B with file-based signal integrity (SI) tools for debugging multiport SI issues and validating circuit models.

The 8.5 GHz MS46524B VNA model has an additional bias tee option available, option 61, which allows the user to provide DC power for biasing devices while testing.

The ShockLine MS46524B series comes in a 3U high chassis and uses the same GUI, software, command syntax, drivers, and programming environments as the rest of the ShockLine family.

Specified performance to 43.5 GHz with Extended K™ ports
Simple signal integrity testing of passive multiport and differential devices
Advanced time domain option provides tools for signal integrity analysis
Wide dynamic range enables measurement of very low reflection artifacts
Excellent corrected directivity minimizes measurement uncertainty
SmartCal™ auto calibration unit reduces calibration and setup time
Time domain with time gating option enables TDR-like measurements
Modern LAN interface for remote control is faster than GPIB
A common GUI and SCPI interface within the ShockLine family
The compact 3U high chassis allows for the efficient use of rack space
Bias tee option simplifies test setups where the DUT needs DC biasing
Universal Fixture Extraction (UFX) software option provides advanced de-embedding tools for test fixture extraction

Precision Automatic Calibrator Modules

Model Number	Description
MN25208A	2-port USB SmartCal Module, 300 kHz to 8.5 GHz (available with connector options: -001 N(f), -002 K(f), -003 3.5 mm(f)
MN25408A	4-port USB SmartCal Module, 300 kHz to 8.5 GHz (available with N(f) connectors)
MN25218A	2-port USB SmartCal Module, 1 MHz to 20 GHz (available with K(f) connectors)
MN25418A	4-port USB SmartCal Module, 300 kHz to 20 GHz (available with K(f) connectors)
36585K-2M	K Precision AutoCal Module, 70 kHz to 40 GHz, K(m) to K(m)
36585K-2F	K Precision AutoCal Module, 70 kHz to 40 GHz, K(f) to K(f)
36585K-2MF	K Precision AutoCal Module, 70 kHz to 40 GHz, K(m) to K(f)
2000-1809-R	Serial to USB Adapter (required for use with 36585 AutoCal module)

Optical/Electrical Calibration Modules

Model Number	Description
MN4765B-0040	2-port, 800 nm to 890 nm, O/E Calibration Module, 70 kHz to 40 GHz
MN4765B-0042	2-port, 800 nm to 1700 nm, O/E Calibration Module, 70 kHz to 40 GHz
MN4675B-0043	2-port, 800 nm to 1700 nm, 1300 nm to 1330 nm, and 1530 nm to 1620 nm, O/E Calibration Module, 70 kHz to 40 GHz
MN4765B-0070	2-port, 1480 nm to 1620 nm, O/E Calibration Module, 70 kHz to 70 GHz
MN4765B-0071	2-port, 1300 nm to 1330 nm, O/E Calibration Module, 70 kHz to 70 GHz
MN4765B-0072	2-port, dual 1530 nm to 1620 nm and 1300 nm to 1330 nm, O/E Calibration Module, 70 kHz to 70 GHz

Mechanical Calibration Kits

Model Number	Description
3650A	SMA/3.5 mm Calibration Kit, Without Sliding Loads, DC to 26.5 GHz, 50 Ω
3650A-1	SMA/3.5 mm Calibration Kit, With Sliding Loads, DC to 26.5 GHz, 50 Ω
3652A	K Connector Calibration Kit, Without Sliding Loads, DC to 40 GHz, 50 Ω
3653A	N Connector Calibration Kit, Without Sliding Loads, DC to 18 GHz, 50 Ω
OSLN50A-8	Precision N Male Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω
OSLNF50A-8	Precision N Female Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω
TOSLN50A-8	Precision N Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω
TOSLNF50A-8	Precision N Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω
OSLN50A-18	Precision N Male Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω
OSLNF50A-18	Precision N Female Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω
TOSLN50A-18	Precision N Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω
TOSLNF50A-18	Precision N Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω
TOSLK50A-20	Precision K Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 20 GHz, 50 Ω
TOSLKF50A-20	Precision K Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 20 GHz, 50 Ω
TOSLK50A-40	Precision K Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 40 GHz, 50 Ω
TOSLKF50A-40	Precision K Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 40 GHz, 50 Ω
TOSLK50A-43.5	Precision K Male Through/Open/Short/Load Mechanical Calibration Tee with S1P data, DC to 43.5 GHz, 50 Ω
TOSLKF50A-43.5	Precision K Female Through/Open/Short/Load Mechanical Calibration Tee with S1P data, DC to 43.5 GHz, 50 Ω

Verification Kits

Model Number	Description
3663-4	N Connector Verification Kit
3668-4	43.5 GHz K Connector Verification Kit

Cables and Adapters

Model Number	Description
N120-6	RF Cables, Semi-Rigid, N(m) to N(m), 1 each, 0.01 to 18 GHz, 50 Ω, 15 cm (5.9 in)
NS120MF-6	RF Cables, Semi-Rigid, N(f) to N(f), 1 each, 0.01 to 18 GHz, 50 Ω, 15 cm (5.9 in)
1091-26-R	SMA(m) to N(m), DC to 18 GHz, 50 Ω
1091-27-R	SMA(f) to N(m), DC to 18 GHz, 50 Ω
1091-80-R	SMA(m) to N(f), DC to 18 GHz, 50 Ω
1091-81-R	SMA(f) to N(f), DC to 18 GHz, 50 Ω
71693-R	Ruggedized adapter, K(f) to N(f), DC to 18 GHz, 50 Ω
34NN50A	Precision Adapter, N(m) to N(m), DC to 18 GHz, 50 Ω
34NFNF50	Precision Adapter, N(f) to N(f), DC to 18 GHz, 50 Ω
34NK50	Precision Adapter, N(m) to K(m), DC to 18 GHz, 50 Ω
34NKF50	Precision Adapter, N(m) to K(f), DC to 18 GHz, 50 Ω
34NFK50	Precision Adapter, N(f) to K(m), DC to 18 GHz, 50 Ω
34NFKF50	Precision Adapter, N(f) to K(f), DC to 18 GHz, 50 Ω
K220B	Precision Adapter, K(m) to K(m), DC to 40 GHz, 50 Ω
K222B	Precision Adapter, K(f) to K(f), DC to 40 GHz, 50 Ω
K224B	Precision Adapter, K(m) to K(f), DC to 40 GHz, 50 Ω
33KK50C	Calibration Grade Adapter, K(m) to K(m), DC to 43.5 GHz, 50 Ω
33KKF50C	Calibration Grade Adapter, K(m) to K(f), DC to 43.5 GHz, 50 Ω
33KFKF50C	Calibration Grade Adapter, K(f) to K(f), DC to 43.5 GHz, 50 Ω
34VFK50A	Precision Adapter, V(f) to K(m), DC to 43.5 GHz, 50 Ω
34VFKF50A	Precision Adapter, V(f) to K(f), DC to 43.5 GHz, 50 Ω
34VK50A	Precision Adapter, V(m) to K(m), DC to 43.5 GHz, 50 Ω
34VKF50A	Precision Adapter, V(m) to K(f), DC to 43.5 GHz, 50 Ω

Test Port Cables, Flexible, Ruggedized, Phase Stable

Model Number	Description
15NNF50-1.0B	Test Port Cable, Flexible, Phase Stable, 1.0 m (39”), DC to 18 GHz, N(f) to N(m), 50 Ω
15NNF50-1.5B	Test Port Cable, Flexible, Phase Stable, 1.5 m (59”), DC to 18 GHz, N(f) to N(m), 50 Ω
15NN50-1.0B	Test Port Cable, Flexible, Phase Stable, 1.0 m (39”), DC to 18 GHz, N(m) to N(m), 50 Ω
15LL50-1.0A	Test Port Cable, Armored, Phase Stable, 1.0 m (39”), DC to 20 GHz, 3.5 mm(m) to 3.5 mm(m), 50 Ω
15LLF50-1.0A	Test Port Cable, Armored, Phase Stable, 1.0 m (39”), DC to 20 GHz, 3.5 mm(m) to 3.5 mm(f), 50 Ω
15KK50-1.0A	Test Port Cable, Armored, Phase Stable, 1.0 m (39”), DC to 20 GHz, K(m) to K(m), 50 Ω
15KKF50-1.0A	Test Port Cable, Armored, Phase Stable, 1.0 m (39”), DC to 20 GHz, K(m) to K(f), 50 Ω
3671KFS50-60	Test Port Cable, Flexible, Phase Stable, DC to 26.5 GHz, K(f) to 3.5 mm(m), 63.5 cm, 50 Ω
3671KFK50-60	Test Port Cable, Flexible, Phase Stable, DC to 40 GHz, K(f) to K(m), 63.5 cm (25 in), 50 Ω
3671KFKF50-60	Test Port Cable, Flexible, Phase Stable, DC to 40 GHz, K(f) to K(f), 63.5 cm (25 in), 50 Ω
3671KFK50-100	Test Port Cable, Flexible, Phase Stable, DC to 40 GHz, K(f) to K(m), 1 m (38 in), 50 Ω
806-304-R	Flexible Phase Stable Cable, DC to 40 GHz, 36 in (91.5 cm), K(m) – K(f), 50Ω
806-423-R	Flexible Phase Stable Cable, DC to 43.5 GHz, 24 in (61 cm), K(f) – K(f), 50 Ω
806-424-R	Flexible Phase Stable Cable, DC to 43.5 GHz, 24 in (61 cm), K(m) – K(f), 50 Ω
806-425-R	Flexible Phase Stable Cable, DC to 43.5 GHz, 1 m (39.4 in), K(f) – K(f), 50 Ω
806-426-R	Flexible Phase Stable Cable, DC to 43.5 GHz, 1 m (39.4 in), K(m) – K(f), 50 Ω

Phase-Stable 18 GHz, 40 GHz, and 43.5 GHz Semi-Rigid Cables (Armored)

Model Number	Description
3670N50-1	Test Port Cable, Armored, Semi-rigid, 30.48 cm (1 ft), DC to 18 GHz, N(m) to N(f), 50 Ω
3670N50-2	Test Port Cable, Armored, Semi-rigid, 60.96 cm (2 ft), DC to 18 GHz, N(m) to N(f), 50 Ω
3670NN50-1	Test Port Cable, Armored, Semi-rigid, 30.48 cm (1 ft), DC to 18 GHz, N(m) to N(m), 50 Ω
3670NN50-2	Test Port Cable, Armored, Semi-rigid, 60.96 cm (2 ft), DC to 18 GHz, N(m) to N(m), 50 Ω
3670K50A-1	Test Port Cable, Armored, Semi-rigid, 30.48 cm (1 ft), DC to 43.5 GHz, K(m) to K(f), 50 Ω
3670K50A-2	Test Port Cable, Armored, Semi-rigid, 60.96 cm (2 ft), DC to 43.5 GHz, K(m) to K(f), 50 Ω

USB Power Sensors

Model Number	Description
MA24106A	True-RMS USB Power Sensor, 50 MHz to 6 GHz
MA24108A	True-RMS USB Power Sensor, 10 MHz to 8 GHz
MA24118A	True-RMS USB Power Sensor, 10 MHz to 18 GHz
MA24126A	True-RMS USB Power Sensor, 10 MHz to 26 GHz
MA24330A	Microwave CW USB Power Sensor, 10 MHz to 33 GHz
MA24340A	Microwave CW USB Power Sensor, 10 MHz to 40 GHz
MA24350A	Microwave CW USB Power Sensor, 10 MHz to 50 GHz

Tools

Model Number	Description
01-200	Calibrated Torque End Wrench, GPC-7 and Type N
01-201	Torque End Wrench, 5/16 in, 0.9 N·m (8 lbf·in) (for tightening male devices, for SMA, 3.5 mm, 2.4 mm, K, and V connectors)
01-203	Torque End Wrench, 13/16 in, 0.9 N.m (8 lbf·in) (for tightening ruggedized SMA, 2.4 mm, K and V test port connectors)
01-204	End Wrench, 5/16 in, Universal, Circular, Open-ended (for SMA, 3.5 mm, 2.4 mm, K, and V connectors)

Anritsu has partnered with the following industry-leading companies to provide a variety of proven material measurement capabilities that are compatible with the VectorStar and ShockLine vector network analyzer families.

Material Measurements

	AET, Inc Providing Resonant Cavity and Open Coaxial Resonator material measurement solutions with MS46122B. Microwave Dielectric Measurement System
	Compass Technology Choose from off-the-shelf or custom-designed RF material measurement systems able to measure material properties from 100 MHz to 90 GHz. These solutions include: focused beam, resonant cavity, waveguides, spot probes, free space measurement systems, and more. Anritsu and Compass Technology Group Material Measurements Solutions Compass Technology Group VectorStar Integration [video]
	Keycom Technologies Select from a variety of material measurement solutions that leverage various methods including: resonator, frequency change, probe type, co-axial tube and waveguide type S-parameter, free space, capacitance, epsilometery, and more. Anritsu and Keycom Material Measurement Solution
	SWISSto12 Providing hardware and software technology capable of measuring: solid samples; soft sample and foam; liquid samples and powder; thin films; dielectric coatings and multilayer materials; alumina plate; and more. Anritsu and SWISSto12 Material Measurement Solution

Delta-L PCB insertion loss testing

Polar Instruments
Provides an integrated test solution for Delta-L PCB insertion loss testing.

Atlas Delta-L Insertion Loss Test System for Anritsu ShockLine MS46524B

Applications

Differential Devices

Cables
Connectors
PCBs

Automotive

RF (FAKRA) connectors
Driver assistance radar

Mobile

UE – micro coaxial RF connectors
UE – antennas, switches, diplexers
5G network components

General Purpose

Passive Device Testing
Connectors
Cables
Electromechanical
Switches
Attenuators
Couplers
Filters
Isolators
Circulators
Radar connectors
Near-field and far-field antenna measurements

System Integration Applications

System calibration
Differential path-loss characterization
General multi-port s-parameter and time domain measurements

Simple Active Applications

Amplifier characterization

Wireless Power Transfer Applications

KQ product
Maximum efficiency

Optical to Electrical, Electrical to Optical, and Optical to Optical Applications

Photo receiver
Laser modulator
Optical transceiver

Frequency Options

Option	Description
MS46524B-010	50 kHz to 8.5 GHz
MS46524B-020	50 kHz to 20 GHz
MS46524B-043	50 kHz to 43.5 GHz

Other Options

Option	Description
MS46524B-001	Rack mount, adds handles and removes feet for shelf-mounting into a 19 in. universal rack
MS46524B-002	Time domain with time gating
MS46524B-022	Advanced time domain
MS46522B-024	Universal Fixture Extraction
MS46524B-061	Bias Tees (Port 1, 2, 3, and 4) (For MS46524B units with Option 10 only)

Related Links

Library

Brochure

Brochure	Release Date
Anritsu's RF and Microwave Test and Measurement Solutions Product Brochure	05/06/2023
5G Solutions Catalog 2023	12/04/2023
ShockLine MS46524B Quick Fact Sheet	28/02/2023
Vector Network Analysis Product Portfolio	19/12/2022
Anritsu and Polar Instrument Solution for Delta-L 4.0 Measurement Based on Atlas SI Software with Anritsu 4-Port Benchtop VNAs Solution Flyer	11/05/2022
VNA Fundamentals Poster	30/04/2021
ShockLine Vector Network Analyzer Family Product Brochure	04/08/2020

Datasheet

Datasheet	Release Date
ShockLine VNA MS46524B Technical Data Sheet	05/04/2022
ShockLine VNA and Site Master S331P Product Information, Compliance, and Safety	01/12/2020
Performance ShockLine VNA Declaration of Conformity	09/06/2017
Soft Case Declaration of Conformity	09/06/2017

Application Note

Application Note	Release Date
Offline Split 2x-Thru Touchstone File to Two 1x-Thru Using Equation Editor in ShockLine Vector Network Analyzer Application Note	11/05/2022
Accessing 43.5 GHz Measurements with Traceability Application Note	30/06/2020
Material Measurements with Vector Network Analyzers Application Note	26/05/2020
Utilizing Line-Reflect-Line (LRL) Calibration Method to Measure a Surface-Mount Bandpass Filter on a Fixture Application Note	28/04/2020
Performing Sequential Peeling Extraction and De-Embedding with an Anritsu ShockLine Vector Network Analyzer Application Note	04/02/2020
Electro-Optical Measurements Using Anritsu VNAs	24/01/2020
Factors in Choosing a VNA for Microwave Applications in Manufacturing Application Note	11/12/2019
Consider Source Harmonics When Characterizing Filters with VNAs	13/08/2019
Distinction Between TRL and LRL	26/03/2019
Technique for Improving Low Insertion Loss VNA Measurements Application Note	25/09/2018
Electrical-to-Optical and Optical-to-Electrical (E/O and O/E) converter measurements	06/02/2018
Understanding Vector Network Analysis Application Note	27/07/2017
LRL-LRM Calibration Theory and Methodology Application Note	21/03/2017
Vector Network Analyzer Use in Antenna Measurement Systems	25/10/2016
VNA Signal Integrity Measurement Challenges Application Brief	12/09/2016

Leaflet

Leaflet	Release Date
Anritsu and Compass Technology Group Material Measurements Solution	27/01/2022
Anritsu and SWISSto12 Material Measurements Solution	27/01/2022
Anritsu and Keycom Material Measurement Solution	27/01/2022
Anritsu, Diamond Engineering, and Diamond Microwave Chambers Antenna Measurement Solution	26/08/2020
Anritsu Vector Network Analyzers — The Perfect Tool for Electro-Optical Measurements	06/02/2018

White Paper

White Paper	Release Date
Superposition vs. True-Balanced: What's Required for your Signal Integrity Application White Paper	23/08/2018
Modern Architecture Advances Vector Network Analyzer Performance White Paper	08/11/2016
A Guide to Making RF Measurements for Signal Integrity Applications	31/10/2016
Measuring Channel Operating Margin	10/10/2016

Selection Guide

Selection Guide	Release Date
ShockLine Vector Network Analyzers Selection Guide	01/04/2020

Catalog

Catalog	Release Date
Electronic Measuring Instruments Digest 2023	23/03/2023
Precision RF & Microwave Components Catalog	26/07/2022

Quick Start Guide

Quick Start Guide	Release Date
ShockLine Series Vector Network Analyzers Verification Kits and Performance Verification Software	05/04/2022

Operations Manual

Operations Manual	Release Date
MN4765B O/E Calibration Module Operation Manual	11/04/2023
ShockLine MS46522B and MS46524B Series Operation Manual	05/04/2022

User Guide

User Guide	Release Date
ShockLine MS46522B/524B User Interface Reference Manual	05/04/2022

Measurement Guide

Measurement Guide	Release Date
ShockLine MS46522B and MS46524B Calibration and Measurement Guide	15/06/2021

Programming Manual

Programming Manual	Release Date
ShockLine MS46xxxA/B and MS4652xB VNA Programming Manual	05/04/2022

Maintenance Manual

Maintenance Manual	Release Date
ShockLine MS4652xB Series VNA Maintenance Manual	14/12/2022

IMAGES

VIDEOS
