被測光纖
|
ITU-T G.653 (DSF)
|
|
光連接器
|
FC, SC, (User Replaceable, PC Type)
|
|
波長
|
1527.60 nm to 1567.13 nm
|
|
波長準確度
|
±0.05 nm (20°C to 30°C)
|
|
預熱時間
|
2 minutes (20°C to 30°C)
|
|
脈衝寬度
|
3/10/30/60/100 µs
|
|
光輸出功率
|
0 to +13 dBm, 0.5 dB Steps
|
|
動態範圍（S/N=1）
|
18 dB (typ.)
Measurement conditions (25℃, Pulse Width: 10 μs, Averaging Times: 216, Distance Range: 1000 km, Smoothing: On, Signal: –57 dBm @ Pin)
|
|
死區
|
0.5 km (Pulse Width: 3 µs)
|
|
距離範圍
|
100 km, 500 km to 12,000 km (in 500 km steps)
With MW90010B-003
100 km, 500 km to 20,000 km (in 500 km steps)
|
|
量測時間
|
15 minutes (Distance Range: 1000 km, Averaging Times: 216)
|
|
尺寸和重量
|
320 (W) × 177 (H) × 451 (D) mm, ≤10 kg
|
