Dual-lane Checkweigher
(available in SSV-h, SSV-i, and SSV-f)

Checkweighers - Anritsu

Request a Quote

Specification

Max product length (SSV-h, i, f)
450, 600, 600 mm
Max product width (SSV-h, i, f)
350, 350, 450 mm
Max product height (SSV-h, i, f)
450, 450, 600 mm
Dimensions (SSV-h)
850 mm H x 730 mm W, Length varies
Dimensions (SSV-i)
850 mm H x 947 mm W, Length varies
Dimensions (SSV-f)
850 mm H x 832 mm W, Length varies
Weigh range (SSV-h, i, f)
0.4-100, 6-600, 6-600 g
Max belt speed (SSV-h, i, f)
15-120, 5-97, 5-120 m/min
IP rating (SSV-h, i, f)
IP30, IP66, IP30

Features

Auto-wizard product setup

Simple operation by single indicator

Smart Measurement Function for improved OEE

Temperature compensation

Anritsu proprietary weigh cell design

Sanitary features

Tool-free belt removal

Clean design with easy access

Waterproof, hygienic design available

Benefits

The space-saving dual-lane configuration allows you to inspect two lanes of products with one unit. Dual-lane checkweighers are typically placed after filling and packaging machines of sticks, tubes, pouches, and flow-wrapped products. Each line can be operated independently from the machine's touchscreen panel. Trend control is also performed individually. Since this configuration can be applied to any series of Anritsu's checkweighers (SSV-h, SSV-i, and SSV-f), it's suitable for a wide range of products, cleaning and sanitation standards, accuracy requirements, and production environments. It also comes with a giveaway feature that calculates product excess both as total weight and percentage, allowing you to adjust filling levels and reduce costs.

Reduction of product giveaway generates ROI from the first day of usage
Great combination of reliability, cost-effectiveness, and versatility
Small footprint: Double throughput with one unit
Same functions and excellent ease of use as single-lane models

Anritsu Academy

Learn more about our Checkweighers and how to use them. Browse our selection of downloadable sell sheets, brochures, white papers, application reports, demo videos, and more.

Keep Your Line Running At Peak Performance

Quicca3, Remote Support, Ethernet/IP & OPC-UA
Our full suite of connectivity and data solutions allows connectivity of your machines, comprehensive live monitoring, archiving and reporting.

QUICCA3

A quality management and control system that monitors equipment status and analyzes production data from one single dashboard at any location.

Remote Support

A software-based service that allows an Anritsu technician to connect remotely to your machine to diagnose issues or demonstrate tasks and functions live to operators.

Ethernet/IP & OPC-UA

Anritsu equipment supports common data communication protocols to execute critical daily operations, such as saving X-ray images, managing logs, or sending operation commands.

Interested in learning more about our inspection solutions or other products?

Get in touch with us today!
