Overview

描述

• High optical output power
• Wide spectral half width
• Built-in monitor photo diode

Superluminescent Diodes bridge the gap between Laser Diodes and Light Emitting Diodes.

Like an LD, the SLD provides a high optical output power. Anritsu's SLD feature broadband spectrum characteristics, typically found only in LEDs, and a low coherence. Our SLD features a low coherence length having a high intensity at a narrow radiation angle. This makes the SLD much easier to couple to a fiber for a broad range of applications. SLDs are ideal for Optical Coherence Tomography, fiber sensors such as temperature and strain gauges as well as applications in test and measurement instrumentation.

Model Name	Model Number	Package	Optical output power [mW/mA]	Center Wavelength [nm]	Spectral Width [nm]	Max Temp [degree]
0.8µm SLD CAN	AS8K215GY30M	CAN	5/70	830	Spectral Width [nm]	Max Temp [degree]	15	Tc=70
0.8µm SLD Module	AS8E210GP30M	Cylindrical	1/70		15
0.8µm SLD Module	AS8B112G230M	Butterfly	2/120		14
0.8µm SLD Module	AS8B115G230M	Butterfly	5/150		14
0.8µm SLD Module	AS8B115L240M	Butterfly	5/150	840	50
1.31µm SLD Module	AS3B119GM10M	Butterfly	15/400	1310	55	Tc=75
1.31µm SLD Cylindrical Module	AS3E113HJ10M	Cylindrical	3/250	1310	53	Tc=50
1.55µm SLD Module	AS5B125EM50M	Butterfly	25/500	1550	60	Tc=75
1.65µm SLD Module	AS6B118GM50M	Butterfly	10/350	1650	70	Tc=75
