Overview

軟體

VectorStar MS4640B
為 MS4640B 下載 VectorStar 應用程式 [軟體和 DSP 韌體] 更新

Release Date: July 22, 2020
Software and DSP Firmware: 2020.5.2

重要提示: 包含新軟體安裝說明。 安裝之前請一定要閱讀「VectorStar 如何安裝」文件。

(將下載的檔案解壓縮到快閃磁碟機,然後根據安裝 .rtf 檔案中的說明操作)

Download button



若您無法下載軟體,請聯繫我們

VectorStar Windows 10 Upgrade Path Options

The VectorStar family of Vector Network Analyzers (VNA’s) has been shipping with Windows 7 operating system since March 2014. With termination of Microsoft support for Windows 7 by the end of October 2020, all new VectorStar MS464xB network analyzers now ship with Windows 10 IoT (32-bit) operating system. We offer upgrade paths for customers wishing to transition existing VectorStar units from windows 7 to Windows 10. The method for transitioning existing Windows 7-equipped units to Windows 10 depends on the age of the unit. Two upgrade paths are available. Identification of which upgrade is required for a specific unit is simple and only depends on knowledge of the model and serial number. If customers do not wish to transition to Windows 10, the Windows 7-fitted units will continue to function normally, albeit with the lack of ongoing Microsoft support for bug and security fixes. For more information please contact your nearest Anritsu representative.

O/S Patches

VectorStar MS4640B
Download WannaCry Security Patch
for Windows 7

To help protect your instrument from a known vulnerability in the Microsoft Windows Operating system that can be exploited by the WannaCry ransomware, we recommend customers install this security patch.

Revision 1.0

(Unzip the down-loaded file into a flash drive, then follow the instructions in the installation .pdf file)

Download

VectorStar MS4640A
Download WannaCry Security Patch
for Windows 7

To help protect your instrument from a known vulnerability in the Microsoft Windows Operating system that can be exploited by the WannaCry ransomware, we recommend customers install this security patch.

Revision 1.0

(Unzip the down-loaded file into a flash drive, then follow the instructions in the installation .pdf file)

Download

If you are unable to download our software, please contact us

Utilities

   Exact Uncertainty Calculator (version 2.04 版)
此軟體可為 VectorStar 和 Lightning 系列 VNA 計算和繪製透射和反射、幅度和相位、測量不確定性。  它考慮不同的校準方法和工具、以及不同的條件,例如 IF BW,以及為透射和反射不確定性分別考慮非零 s11、s22 和 s21、s12 條件。

  WindowsGPIB(3.79 版)
WindowsGPIB 是 Windows® 程式,根據鍵盤命令或命令檔案透過 GPIB 傳送和接收程式資料,類似 NI WIBIC 但更友好。  它是開發 ATE 程式時測試助憶鍵和命令的優秀工具。  Windows GPIB 僅支援 NI GPIB。

  Noise Figure Uncertainty Calculator(1.0.1 版)
VectorStar Noise Figure Uncertainty Calculator 是一個獨立程式,可幫助使用者在使用 VectorStar VNA Option 041 – 雜訊指數時方便地確定測量不確定性。 該計算器可安裝到 VectorStar 儀器桌面,也可安裝到 Windows XP/Windows 7 電腦上。

  CapVNA(版本 1.0.1)
CapVNA 是一款 Windows 程式,用於採集、顯示、儲存和列印 VectorStar VNA 的圖形和文字資料。 顯示的資料可以從之前 VNA 儲存到的快閃磁碟機上載入,也可透過 GPIB 埠直接從 VNA 採集。 顯示的資料可使用各種格式儲存到電腦內置磁碟機或網路磁碟機上,以及使用本地或網路印表機列印(包括彩色)。

程式設計範例(MS4640A 和 MS4640B)
下面的檔案包含 VectorStar 遠端程式設計範例的源代碼,已列在程式設計手冊中。  可根據需要複製貼上到您的應用程式中。

  C#, VectorStar 程式設計範例(1.0 版)

  LabVIEW, VectorStar 程式設計範例(1.0 版)

  LabWindows CVI, VectorStar 程式設計範例(1.0 版)

LabView

  LabView® 8.2.1 或更新版本

  Lab Windows CVI® 7.1 版

LabWindows/CVI

  LabWindows/CVI 7.1 或更新版本

Visual Studio .NET (wrapper only)

  Visual Studio .NET 2003

資料庫
影片
VectorStar VNAs deliver Out of this world accuracy

Out of This World Accuracy
VectorStar delivers new standard in broadband performance, on-wafer active and passive devices

Vector Network Analysis for Components and Subsystems

應用於零組件及子系統的向量網路分析儀
The VectorStar® family is Anritsu's Premium VNA line, offering the highest overall performance on a modern platform. The MS4640A Series offers the best performance covering a span of 70 kHz to 70 GHz.

Introducing Cutting-edge Pulse Measurement Capability with Anritsu's new VectorStar B Series VNAs equipped with PulseView

VectorStar B 向量網路分析儀系列提供頂尖脈衝量測能力
Testing radar sub-systems and components. On-wafer device characterization. Analysis tools.
