NEW! 2-Port PIM Hunting Certification

2-Port PIM Hunting Certification

External PIM hunting is challenging on AT&T cell sites where both Band 14 (FirstNet) and Band 17 are deployed together. PIM sources seen by both bands have a significantly higher impact on system performance than PIM sources seen by only one band. With traditional PIM test equipment, all PIM sources must be mitigated to the same low level to guarantee site performance. As a result, crews may waste time and money over-mitigating PIM sources seen by only one band that has little impact on site performance.

An external 2-port filter is being used in the class along with Anritsu test equipment to split the F1 and F2 test tones from the PIM analyzer, delivering one tone to the Band 14 antenna and the other tone to the Band 17 antenna. The tones only re-combine at PIM sources seen by both bands, allowing mitigation crews to focus their effort on the PIM sources with the highest impact on site performance.

Course Description:
2-Port PIM Hunting Certification is an advanced one-day instructor-led training course that teaches wireless professionals how to use a 2-port filter and Anritsu test equipment to locate external PIM sources at cell sites. The course uses a combination of theory and practical, hands-on exercises to build testing confidence in a real world simulation.

Time: 8:00am to 5:00pm

Price: $1,395 per student for the Anritsu public classes shown below.

Prerequisites

Students MUST complete the External PIM Hunting Certification course prior to attending this advanced course. You can register for this prerequisite course here - External PIM Hunting Certification

Who Should Attend
  • Wireless operators
  • Installation contractors
  • Troubleshooting experts
  • Site maintenance engineers
  • RF optimization engineers
  • Field technicians
  • Installers
What You Will Learn
  • Why 2-port PIM testing is necessary
  • How the 2-port process works
  • Test equipment options
  • Required test procedures
  • M-PiLOT data interpretation
  • How to use a Yagi antenna to locate PIM sources “off-the-roof” or beyond the tower
  • New AT&T reporting requirements
Why Anritsu Training?

Hands-on: Learn by doing the task and not by watching. 60% of the course is hands-on.

Critical Emphasis: Fine tune the points and techniques that are of particular importance to your operations. Learn industry standard best practices and reduce costly rework.

Proven History: With over 20 years of experience certifying RF technicians, Anritsu is the gold standard in training with Anritsu factory-trained instructors and Anritsu test and measurement equipment.

Additional Information

PLEASE NOTE BEFORE REGISTERING:
Classes will be postponed or cancelled if a minimum registration of 5 students is not met two weeks prior to the class dates. Credit card orders are authorized but not charged until the class is confirmed. Online orders can only be processed if the billing address is in the United States.

CANCELATION POLICY
Once a class is confirmed, any student wishing to cancel must provide written notice to us-training(ATMARK)anritsu.com at least 14 days prior to the class date or be subject to a cancellation fee of up to 100% of the registration fee.

3/13/2020 - 3/13/2020

Location

MORGAN HILL, CA: Hosted by Anritsu @ 490 Jarvis Drive, Morgan Hill, CA 95037

No. of Available seats

8


Price per Student

$1395.00

Register Now
