Anritsu Infivus Bulk Fresh Food X-Ray Inspection System

Bulk Fresh Food X-Ray Inspection System

This product has been discontinued
Standard Features
  • Missing Product Area Detection
  • Virtual Weighing
  • Shape Detection
  • Mask Functions
  • Multi-Lane Inspection
  • Flow Direction Change
  • Variable Line Heights
  • Statistics
  • NG History
  • RS232C
  • Ethernet
  • USB Data Port

Optional Features
  • Package Check
  • Void Check
  • Count Detection
  • CE Marking
  • FCC Compliance
  • Rejection Confirmation

Food inspection for bulk flow of unpacked fresh food cannot be completed without one of the two bulk/fresh food models from the KD74 series. The two models can measure different product sizes, including:
  • Product Size: 240 mm X 50 mm
  • KD7405ABWH
  • Product Size: 390 mm X 50 mm
  • KD7416ABWH
During this kind of food safety inspection, x-ray protection curtains are not used because the food is unpackaged and usually contains raw meat and fish. This allows for a quick and seamless food inspection process that keeps the food sanitized.

The detection technology for the bulk/fresh food x-ray inspection equipment can detect a FE sphere and SUS sphere as small as 0.3 mm dia., and a SUS wire of 0.2 mm dia. X 2 mm long. Make sure food stays fresh with the quick and efficient inspection times by the KD7405ABWH and KD7416ABWH series.

World Class Reliability
Anritsu x-ray inspection systems have evolved over the years, and have been installed globally in the food and pharmaceutical industries. This history of reliability is built into every design, backed by our preventative maintenance crew.

Long-Term Flexibility
The Anritsu x-ray system includes virtually every algorithm you may need to inspect your product. In addition, features such as virtual weighing, shape detection, flow direction change, Ethernet connection and many other features provides the user with a long- term, flexible solution for any new applications that may require x-ray inspection.

Ease of Use Increases Efficiencies
Anritsu installations are successful because they are designed to be easy-to-use and easy-to-understand. Rather than requiring a full knowledge of the technology, graphs and color coded algorithm feedback provides operators with the information required to create new products and adjust existing settings with ease, eliminating the need for factory support.

Ease of Maintenance
Reliability in the design minimizes the need for maintenance but when required, a full suite of system diagnostics, plug and play boards and easy release conveyor design offers quick maintenance and minimizes any downtime.

Best in Class Accuracy

  • Flexibility - NOT ale carte pricing
  • Reliability resulting in minimal to zero downtime
  • Efficiency in parts, support and documentation
