Vector Network Analyzers Handheld

Vector Network Analyzers - Handheld
The VNA Master solution is the industry’s broadest frequency solution to address cable, antenna, component, and signal analysis needs. Ideal for spectrum monitoring, broadcast proofing, interference analysis, RF and microwave measurements, regulatory compliance, and 3G/4G and wireless data network measurements.
Model Number
Frequency
Dynamic range
Sweep Speed
Directivity
VNA Master MS2026C
MS2026C
VNA Master
5 kHz — 6 GHz ≥ 90 dB (Transmission @ 6 GHz) 350 µsec/point ≥ 42 dB
VNA Master MS2027C Vector Network Analyzer
MS2027C
VNA Master
5 kHz — 15 GHz ≥ 85 dB (Transmission @ 15 GHz) 350 µsec/point ≥ 42 dB
VNA Master MS2028C
MS2028C
VNA Master
5 kHz — 20 GHz ≥ 85 dB (Transmission @ 20 GHz) 350 µsec/point ≥ 42 dB
VNA Master + Spectrum Analyzer MS2036C
MS2036C
VNA Master + Spectrum Analyzer
VNA:5 kHz — 6 GHz

SPA: 9 kHz — 9 GHz
≥ 90 dB (Transmission @ 6 GHz) 350 µsec/point ≥ 42 dB
VNA Master MS2037C Vector Network Analyzer
MS2037C
VNA Master + Spectrum Analyzer
VNA: 5 kHz—15 GHz

SPA: 9 kHz—15 GHz
≥ 85 dB (Transmission @ 15 GHz) 350 µsec/point ≥ 42 dB
VNA Master + Spectrum Analyzer MS2038C
MS2038C
VNA Master + Spectrum Analyzer
VNA: 5 kHz — 20 GHz

SPA: 9 kHz — 20 GHz
≥ 85 dB (Transmission @ 20 GHz) 350 µsec/point ≥ 42 dB
VNA Master MS2024B
MS2024B
VNA Master
500 kHz — 4 GHz ≥ 100 dB (Transmission) 850 µsec/point ≥ 42 dB
MS2025B Vector Network Analyzers
MS2025B
VNA Master
500 kHz — 6 GHz ≥ 100 dB (Transmission) 850 µsec/point ≥ 42 dB
MS2034B
MS2034B
VNA Master + Spectrum Analyzer
VNA 500 kHz — 4 GHz

SPA 9 kHz — 4 GHz
≥ 100 dB (Transmission) 850 µsec/point ≥ 42 dB
VNA Master + Spectrum Analyzer MS2035B
MS2035B
VNA Master + Spectrum Analyzer
VNA 500 kHz — 6 GHz

SPA 9 kHz — 6 GHz
≥ 100 dB (Transmission) 850 µsec/point ≥ 42 dB
