X線検査機 デュアルエナジセンサ搭載モデル - X-ray Inspection System Dual Energy Sensor Dual X

X-ray Inspection System

DualX [Dual Energy]
This product has been discontinued

Principle and features of dual energy sensor system

Different materials have varying energy-dependent x-ray attenuation coefficients. X-ray images acquired at high energy and low energy will exhibit different attenuation characteristics.

X-ray energy / Attenuation coefficient

The x-rays generated from an x-ray inspection system have several energy levels. The dual energy inspection system produces two different images from two different energy x-rays simultaneously.

The dual energy inspection system

High energy x-rays produce a brighter image and low energy x-rays produces a darker image. By subtracting the two images acquired at different energies, the system eliminates an image having the same gray level, leaving only contaminants.

Dual energy subtraction better highlights contaminants

The dual energy technology delivers the following unique features compared to conventional X-ray technology:
(1) Low density items can be detected.
(2) Even overlapping products can be inspected without false rejecting.

Dual energy X-ray Image
Overview

Analyzing two different x-ray energy signals, it clearly distinguishes contaminants from products. Performs accurate inspection of low density bones in metal and overlapping products.

  • For dry/wet products
  • Protection class: IP66
  • X-ray output: High (max.350W) / Middle to High (max.210W)
  • System range: High Power DualX / Standard model
Detection Areas

A variety of models is available for a wide range of products. For details of detection areas, please submit an online inquiry form.

Model
Detection area
KD7416AWZE/ADWDE
検査可能範囲 - Detection Areas
KD7416ACWZE
検査可能範囲 - Detection Areas
KD7416DWZ
検査可能範囲 - Detection Areas
External Dimensions

[Example model] Maximum width: 390 mm, Maximum height: 150 mm (KD7416DWZ)

External Dimensions
Specifications
Model
KD7416DWZ
X-ray output
Tube voltage 25 to 80 kV, tube current 0.4 to 10.0 mA, output 10 to 350 W
Safety
X-ray leakage maximum 1μSv/h or less, prevention of x-ray leakage by safety devices
Display
15-inch color TFT LCD (unified image monitoring screen and operation screen)
Operation method
Touch panel (with touch buzzer)
Product size 1
Maximum width 390 mm, maximum height 150 mm (see drawing for detection area)
Belt width
420 mm
Masking function
Equipped as standard
Missing product detection function
Equipped as standard
Clip check function
Equipped as standard
Preset memory
Maximum 100
Belt speed 2 /Maximum product weight 3
5 to 60 m/min, maximum 5 kg
5 to 40 m/min, maximum 10 kg (optional)
Power requirements 4, 5, 6
100 to 120 or 200 to 240 Vac, single phase, 50/60 Hz, 1.0 kVA, rush current 80 A (typ.) (5 ms or less)
Mass
280 kg
Environmental conditions 7
Temperature: 0o to 35oC (0o to 40oC with optional air conditioner), relative humidity: 30% to 85%, non-condensing
Protection class
Conveyor IP66, other parts IP40, tool free belt removal
Exterior
Stainless steel (SUS304)
1: The entrance and exit may require covers depending on the length of a product. 2: Variable depending on Product No. 3: Sum total of product weight on the conveyor. 4: Selectable by switching terminals. Note that the rush current shown above is at an AC voltage of 200 V. It varies according to voltage. 5: Allowable power fluctuation range is ± 10%. 6: Installing the air-conditioner option changes the displayed power consumption. 7: The air-conditioner option may be required depending on the operating environment. Note: The noise level of x-ray inspection systems is 77 dB(A).
