Automotive Test Solutions - Intelligent Transport Systems

Test and Measurement Solutions for Automotive Applications

ITS (Intelligent Transport Systems) refers to all types of communication inside or outside the vehicle. In the connected car environment, there are several sensors that are communicating with other vehicles and the road, including lanes and signals. Current applications, known as C2C (Car to Car), V2V (Vehicle to Vehicle) or V2X (Vehicle to X) include radar and eCall, but this will increase in the next few years as vehicles will be equipped with a higher number of sensors and driver aids.

Anritsu offers a complete set of instruments and compact software solutions to make M2M (Machine to Machine) testing easy and compliant with the latest ITS standards, as well as 802.11p.

MD8475A Signaling Tester

MD8475AThe MD8475A is an all-in-one base station simulator supporting all cellular standards and M2M specific applications. It supports services as eCall, IMS, VoLTE, WLAN off-load tests and call-processing tests for smartphones which are now present on vehicles.

In addition, the time required to configure a test environment is greatly reduced by the easy-to-use GUI-based SmartStudio software, as well as supplied test sequences for automatic remote control of the GUI. All this will make M2M testing easy, quick and reliable

  • Supports multimode terminals and all cellular standards, including LTE (2x2 MIMO), LTE-Advanced (Carrier Aggregation).
  • SmartStudio GUI supports easy setup of test environments and functional tests.
  • Automated mobile terminal verification testing with test sequences.

Learn More

MS2830A Spectrum Analyzer

MS2830AThe MS2830A can be used for testing of 2G, 3G, LTE and LTE-Advanced signals on a vehicle-to-vehicle or vehicle-to-x test environment. It supports measurement of modulation and Tx characteristics, including adjacent channel leakage power and spectrum mask as well as spurious measurements requiring a wide dynamic range.

The capture and replay function can be used to better compare the real world effects with simulated designs and performance, which will ensure the product quality

  • 9 kHz to 26.5 GHz/43 GHz frequency range.
  • For wideband down-converter; built-in 1 GHz IF output band
  • Best-of-class wide dynamic range over 6 GHz.

Learn More

MS269xA series

MS2690ASignal Analyzers MS269xA are the latest high performance signal analyzers for next-generation communication applications. The MS269xA Series base units include swept spectrum analysis, FFT signal analysis, and a precision digitizer function. Add options to incorporate a Signal Generator, to turn the instrument into a hassle free, plug and play, one box solution.

  • Frequency range: 50 Hz to 26.5 GHz
  • Offers modulation analysis, such as LTE/LTE-Advanced (FDD/TDD), WLAN IEEE 802.11ac etc. (with optional software)
  • One-Box Tester with the addition of the Signal Generator option
  • Batch capture measurements for the fastest analysis time
  • Supports Noise Figure measurement (option)

Learn More

V2X Message Viewer/Automation Measurement Tool for V2X Tx Test.

V2X Message Viewer

V2X Message Viewer

Automation Measurement Tool for V2X Tx Test

Automation Measurement Tool for V2X Tx Test
  • These software are sample version, and will release commercial version in CY2017Q3.
  • V2X Message Viewer support to check V2X message.
  • Automation Measurement Tool for V2X Tx Test supports easy setting and automatic measurement for RF parametric test.

V2X Message Viewer is V2X message checking tool. It is very difficult to set up environment for objective V2X message check. V2X Message Viewer help to reduce burden of setting up environment for V2X message checking with MS269xA and MS2830A. It supports US and Japanese standards. In the future, they will support European standard as well.

On the other hand, Automation Measurement Tool for V2X Tx Test supports V2X RF parametric test. It helps shorter measurement time and simplified measurement setting up. It supports US, European, and Japanese standards.
